DESCRIPTION

A “MUST-HAVE” PEDAL!

The NS-2 Noise Suppressor eliminates unwanted noise and hum without altering an instrument's natural tone. It's the perfect pedal to quiet down any pedalboard or effects setup.

FEATURES

• Compact noise suppression pedal for eliminating noise and hum in guitar and bass effects and amplifier setups
• Unique noise detection circuit preserves the natural attack and envelope of an instrument's sound
• Threshold and Decay knobs allow for shaping the elimination/suppression as desired
• BOSS 5-year warranty

SPECIFICATIONS

• Nominal Input Level
  • -20 dBu
• Input Impedance
  • 1 M ohm
• Nominal Output Level
  • -20 dBu
• Output Impedance
  • 1 k ohm
• Recommended Load Impedance
  • 10 k ohms or greater
• Bypass
  • Buffered bypass
• Controls
  • MODE selector switch
    DECAY knob
    THRESHOLD knob
    Pedal switch
• Indicator
  • CHECK/MUTE indicator (Used for indication of check battery)
    REDUCTION indicator
• Connectors
  • INPUT jack: 1/4-inch phone type
    OUTPUT jack: 1/4-inch phone type
    SEND jack: 1/4-inch phone type
    RETURN jack: 1/4-inch phone type
    DC IN jack
    9V DC OUT jack
• Power Supply
  • Carbon-zinc battery (9 V, 6F22) or Alkaline battery (9 V, 6LR61)
    AC adaptor (PSA series: sold separately)
• Current Draw
  • 25 mA
• Expected battery life under continuous use
  • Carbon: Approx. 11 hours
    Alkaline: Approx. 24.5 hours
    *These figures will vary depending on the actual conditions of use.
• Accessories
  • Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
    Carbon-zinc battery (9 V, 6F22)
• Options (sold separately)
  • AC adaptor: PSA series
    Parallel DC Cord: PCS-20A

SIZE AND WEIGHT

• Width
  • 73 mm
    2-7/8 inches
• Depth
  • 129 mm
    5-1/8 inches
• Height
  • 59 mm
    2-3/8 inches
• Weight (including battery)
  • 415 g
    15 oz
